Deepwater Level Transmitter
MPM426WS
- · 350m~2000mH2O
- · -20…0~10…80℃
- · Deep-water Application
Used For
Metallurgical Industry, Power Plant, Mines, Oil and Gas in Deep Well, Hydrological Exploration
Leave a MessageMPM426WS
Used For
Metallurgical Industry, Power Plant, Mines, Oil and Gas in Deep Well, Hydrological Exploration
Leave a MessageThe MPM426WS deep water level transmitter is dedicated to measuring oil and gas in deep wells and can be used in harsh environments such as monitoring mine water levels from 350mWC to 2000mWC up to a maximum measurement depth of 2000 metres. In order to improve the sealing performance, the product adopts a special rubber ring bi-directional sealing technology, and the sealing and locking wires are treated separately. For complete sealing and insulation, the cavity is filled with a high vacuum, water and mineral oil resistant sealing silicone material. The product has standard 4~20mA temperature and pressure signal output, and adopts automatic production line to ensure quality, stability and reliability.
Features
• Range: 0mH2O ~ 350mH2O…2000mH2O
• Accuracy: ±0.5%FS (pressure); ±2℃ (temperature)
• Reversed-polarity protection
• Suitable for deepwater level and temperature measurement
Specifications
• Range:
0mH2O ~ 350mH2O…2000mH2O
-20℃ …0℃ ~ 10℃ …80℃；
• Overpressure: ≤2 times FS or 2200mH2O (minimum value is valid)
• Pressure type: sealed gauge, absolute
• Accuracy: ±0.5%FS (pressure); ±2℃ (temperature)
• Zero Thermal Drift: ≤ ±0.02％ FS/℃
Image:
The MPM426WS deep water level transmitter is dedicated to measuring oil and gas in deep wells and can be used in harsh environments such as monitoring mine water levels from 350mWC to 2000mWC up to a maximum measurement depth of 2000 metres. In order to improve the sealing performance, the product adopts a special rubber ring bi-directional sealing technology, and the sealing and locking wires are treated separately. For complete sealing and insulation, the cavity is filled with a high vacuum, water and mineral oil resistant sealing silicone material. The product has standard 4~20mA temperature and pressure signal output, and adopts automatic production line to ensure quality, stability and reliability.
Features
• Range: 0mH2O ~ 350mH2O…2000mH2O
• Accuracy: ±0.5%FS (pressure); ±2℃ (temperature)
• Reversed-polarity protection
• Suitable for deepwater level and temperature measurement
Specifications
• Range:
0mH2O ~ 350mH2O…2000mH2O
-20℃ …0℃ ~ 10℃ …80℃；
• Overpressure: ≤2 times FS or 2200mH2O (minimum value is valid)
• Pressure type: sealed gauge, absolute
• Accuracy: ±0.5%FS (pressure); ±2℃ (temperature)
• Zero Thermal Drift: ≤ ±0.02％ FS/℃
