High Pressure Range Pressure Sensor
MPM283II
- · Φ12.6x10.5mm
- · 0bar~1bar…1000bar
- · -10~80℃ Compensated
Used For
Gas & Liquid Pressure Measurement, Pressure Inspection Meter, Pressure Calibrator
Leave a MessageMPM283II
Used For
Gas & Liquid Pressure Measurement, Pressure Inspection Meter, Pressure Calibrator
Leave a MessageMPM283II high-pressure sensor for tank level is made of a diffused pressure sensing die and stainless steel 316L housing. With a corrugated stainless steel 316L diaphragm, the measured pressure is transmitted to the sensing die through it and internally filled silicon oil. By doing linear correction and temperature compensation, the stable performance of the pressure transducer is guaranteed. With NBR or EPDM O-ring, it is easy for users to install and applicable for different temperature application. The pressure range is 0bar ~ 2.0bar…1000bar and the dimesion of the small pressure sensor is Φ12.6×10.5 mm.
Electrical Performance
• Power supply: ≤2.0mA DC
• Input impedance: 2kΩ~8kΩ
• Output impedance: 3.5kΩ~6kΩ
• Response (10%~90%): <1ms
• Insulated resistor: 100MΩ@100V DC
• Overpressure: 2 times FS or 1100bar (min. value is valid)
Image:
MPM283II high-pressure sensor for tank level is made of a diffused pressure sensing die and stainless steel 316L housing. With a corrugated stainless steel 316L diaphragm, the measured pressure is transmitted to the sensing die through it and internally filled silicon oil. By doing linear correction and temperature compensation, the stable performance of the pressure transducer is guaranteed. With NBR or EPDM O-ring, it is easy for users to install and applicable for different temperature application. The pressure range is 0bar ~ 2.0bar…1000bar and the dimesion of the small pressure sensor is Φ12.6×10.5 mm.
Electrical Performance
• Power supply: ≤2.0mA DC
• Input impedance: 2kΩ~8kΩ
• Output impedance: 3.5kΩ~6kΩ
• Response (10%~90%): <1ms
• Insulated resistor: 100MΩ@100V DC
• Overpressure: 2 times FS or 1100bar (min. value is valid)
Read / Download our Datasheet in PDF
